CP850AVRLCD_F
CP850AVRLCD_L-LPCP850AVRLCD_B

CP850AVRLCD


Intelligent LCD UPS Series

MSRP $119.95

  • Capacity: 850 VA / 510 W
  • Topology: Line Interactive
  • Waveform: Simulated Sine Wave
  • Output: 120 VAC ± 5%
  • Plug type & cord: NEMA 5-15P, 6 ft. cord
  • Outlet types: 9 × NEMA 5-15R
  • Communication: USB, Serial
  • Data line protection: Telephone, Ethernet, Coaxial
  • Management software: PowerPanel® Personal Edition
  • ENERGY STAR® qualified: Yes
  • Warranty: 3 year
  • Connected Equipment Guarantee: $250,000
Where To Buy

    •  RB1280A 12 V8 ACP800AVR, CP825AVR-G, CP825AVRLCD-G, CP825LCD, CP850AVRLCD $38.95

Product Description

CP850AVRLCD | Intelligent LCD UPS Series
Protect SOHO networks, desktop computers, workstations, and peripherals

Product Overview


A mini-tower UPS with line interactive topology, the CyberPower Intelligent LCD CP850AVRLCD provides battery backup (using simulated sine wave output) and surge protection for desktop computers, workstations, networking devices, and home entertainment systems. The CP850AVRLCD uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The CP850AVRLCD comes with a three-year warranty (including coverage of batteries) and a $250,000 Connected Equipment Guarantee.

  • Battery Backup
    Supplies power long enough for equipment to properly shut down when utility power fails. Helps prevent loss of data and minimizes the component stress caused by a hard shutdown.
  • Surge Protection
    Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to prevent damage.
  • Data Line Protection
    Prevents power surges that travel through telephone, coaxial, and Ethernet lines from causing damage to electronics.
  • Line Interactive Topology
    Exists when a line interactive UPS has an autotransformer that regulates low voltages (e.g., brownouts) and over voltages (e.g., spikes) without having to switch to battery.
  • Automatic Voltage Regulation (AVR)
    Provides clean, consistent AC power by automatically regulating low voltages and over voltages, within defined tolerances, when incoming utility power has minor fluctuations.
  • Simulated Sine Wave Output
    Uses pulse wave modulation to generate a stepped, approximated sine wave to supply cost-effective battery backup power for equipment that does not require sine wave output.
  • GreenPower UPS™ Bypass Design
    Is a patented design that allows utility power to bypass the UPS transformer, when AC power is stable, which reduces energy consumption, noise, and heat buildup.
  • Multifunction LCD Panel
    Displays immediate, detailed information on the UPS battery and power conditions, alerting users to potential problems before they can affect critical equipment and cause downtime.
  • Ultra Quiet Design
    Minimizes noise during operation for a quieter work environment.
  • PowerPanel® Personal Edition Software
    Provides a user-friendly dashboard interface for controlling and monitoring the UPS. Free software download available. See the Resources tab.
  • ENERGY STAR
    This model is an ENERGY STAR® certified Uninterruptible Power Supply (UPS) system. ENERGY STAR is the trusted, government-backed symbol for energy-efficient products and practices that help save money and protect the environment.
  • Three-Year Warranty
    CyberPower will repair or replace a defective UPS system (including batteries) within three years of the purchase date. See warranty for details.
  • Connected Equipment Guarantee
    CyberPower will repair or replace properly connected equipment if it is damaged by a power surge.
What’s In The Box

UPS System, User Manual, USB A+B Type Cable

CP850AVRLCD | Intelligent LCD UPS Series
Protect SOHO networks, desktop computers, workstations, and peripherals
General
UPS Topology Line Interactive
ENERGY STAR® Qualified Yes
Energy Saving GreenPower UPS™ Bypass
Input
Voltage 120 VAC
Frequency Range 57 – 63 Hz
Plug Type NEMA 5-15P
Plug Style Right Angle
Cord Length 6 ft
Output
VA 850 VA
Watts 510 W
Automatic Voltage Regulation Yes
On Battery Voltage 120 VAC ± 5%
On Battery Frequency 60 Hz ± 1%
On Battery Waveform Simulated Sine Wave
Outlet Type NEMA 5-15R
Outlets – Total 9
Outlets – Battery & Surge Protected 5
Outlets – Surge-Only Protected 4
Overload Protection Internal Circuitry Limiting

Circuit Breaker

Transfer Time 4 ms
Battery
Runtime at Half Load 7 minutes
Runtime at Full Load 1 minute
Battery Type Sealed Lead-Acid
Battery Size 12V/8.5Ah
Battery Quantity 1
User Replaceable Yes
Replacement Battery Cartridge RB1280A
Replacement Battery Cartridge Quantity 1
Typical Recharge Time 8 hours
Surge Protection & Filtering
Surge Suppression 1,080 J
Phone RJ11 / Ethernet RJ45 1-In, 1-Out (Combo)
Coaxial Protection RG6 1-In, 1-Out
Management & Communications
Multifunction LCD Panel Displays:

Current/Load Level

Runtime

Battery Level

AVR In Use

Battery In Use

Input Voltage

Output Voltage

Output Frequency

Overload

Wiring Fault

Silent Mode

HID Compliant USB Port Yes
LED Indicators Power On

Wiring Fault

Audible Alarms On Battery

Low Battery

Overload

Software PowerPanel® Personal Edition
Serial Port Yes
Physical
Form Factor Mini-Tower
Dimensions – W×H×D (in) 4.25 × 8.75 × 10.5 inches
Weight (lbs) 16.0 lbs
Environmental
Operating Temperature 32 – 95 °F (0 – 35 °C)
Operating Humidity 0 – 95% (non-condensing)
Certifications
Safety UL1778

cUL 107.1

FCC DOC Class B

Environmental RoHS Compliant
Warranty
Product Warranty 3 Years Limited
Connected Equipment Guarantee Lifetime
CEG Amount $250,000
CP850AVRLCD | Intelligent LCD UPS Series
Protect SOHO networks, desktop computers, workstations, and peripherals
GreenPower UPS Technology

GreenPower UPS™ Technology from CyberPower consists of three different energy-saving designs that improve operating efficiency, reduce heat generation, and consume less power than conventional UPS models.

ECO Mode: Our ECO Mode is a form of bypass technology that can be switched on full time, set for noncritical times (such as nights and weekends), or switched off. This flexibility can help conserve power and save money.

Bypass Design: Our patented bypass design allows current to bypass the transformer and automatic voltage regulation (AVR) when utility power is normal, thus reducing energy consumption and associated costs. Because utility power functions normally most of the time, the bypass design allows for substantial energy savings. This technology also reduces heat generation, an important factor in decreasing operating costs.

High-Efficiency Design: significantly decreases power consumption to create an ultra-efficient backup battery for home and office use.


Automatic Voltage Regulation

Automatic Voltage Regulation (AVR) in line interactive UPS systems stabilizes the incoming AC signal to maintain output power at a nominal 120 volts by controlling high and low voltages without resorting to battery power. This significantly increases battery life and lessens the likelihood of data loss, memory freezes, and system crashes.

How AVR Works in a Line Interactive UPS

A line interactive UPS includes an AVR autotransformer—a special type of transformer designed to switch between powered coils of wire in response to variances in utility power input, thereby increasing or decreasing the magnetic field and the resulting output voltage to connected equipment.

This type of UPS tolerates undervoltage brownouts and overvoltage surges without consuming backup battery power by automatically selecting different power taps on the AVR autotransformer. During normal operation, incoming AC power bypasses the autotransformer (where voltage highs and lows are controlled) while also charging the battery. When the incoming voltage falls below the AVR range, the UPS switches to battery backup, and the DC-AC inverter circuitry is engaged. Power will continue to be supplied by the battery-inverter circuit until incoming voltage returns to the range manageable by the AVR.


Transformers and Transformer Outlets

A transformer converts alternating current line voltage to a higher value or a lower value. Transformers rely upon electromagnetic induction, the process which occurs when the alternating current within a circuit generates current in a nearby circuit.

Transformers vary in design and size, as well as using different amounts of current. Small transformers plug into a wall outlet and create low direct current voltages which are used by common electronic devices. Transformer outlets are more widely spaced than other outlets to accommodate transformer block adapters or other adapters that are large in size. Transformer outlets can be used to connect any appropriate device to a surge protector.


CP850AVRLCD | Intelligent LCD UPS Series
Protect SOHO networks, desktop computers, workstations, and peripherals

Shutdown software supports most Window systems

View UPS via the USB connection to your Mac

Shutdown software for Linux. Requires Linux kernel >2.6.12

Shutdown software for Linux. Requires Linux kernel >2.6.12

Shutdown software for Linux. Requires Linux kernel >2.6.12

Shutdown software for Linux. Requires Linux kernel >2.6.12

Shutdown software for Linux. Requires Linux kernel >2.6.12

Shutdown software for Linux. Requires Linux kernel >2.6.12

CP850AVRLCD | Intelligent LCD UPS Series
Protect SOHO networks, desktop computers, workstations, and peripherals
Where is the serial number located on the unit?

The serial number is located on a white label adhered to the unit. The serial number is shown directly underneath the barcode.

CP850AVRLCD | Intelligent LCD UPS Series
Protect SOHO networks, desktop computers, workstations, and peripherals
 Model Output VAOutput WattsOutletsForm FactorWaveform MSRP
 CP600LCD 600 VA340 W8 x NEMA 5-15RCompactSimulated Sine Wave $74.95
 CP750LCD 750 VA420 W8 x NEMA 5-15RCompactSimulated Sine Wave $87.95
 CP825LCD 825 VA450 W8 x NEMA 5-15RCompactSimulated Sine Wave $91.95
 CP685AVRLCD 685 VA390 W8 x NEMA 5-15RCompactSimulated Sine Wave $97.95
 AVRG750LCD 750 VA450 W12 x NEMA 5-15RCompactSimulated Sine Wave $99.95
 CP825AVRLCD 825 VA450 W8 x NEMA 5-15RCompactSimulated Sine Wave $105.95
 AVRG900LCD 900 VA480 W12 x NEMA 5-15RCompactSimulated Sine Wave $125.95
 CP850AVRLCD 850 VA510 W9 x NEMA 5-15RMini-TowerSimulated Sine Wave $119.95
 CP1000AVRLCD 1000 VA600 W9 x NEMA 5-15RMini-TowerSimulated Sine Wave $124.95
 CP1350AVRLCD 1350 VA810 W8 x NEMA 5-15RMini-TowerSimulated Sine Wave $155.95
 CP1500AVRLCD 1500 VA900 W8 x NEMA 5-15RMini-TowerSimulated Sine Wave $179.95
 BRG850AVRLCD 850 VA510 W10 x NEMA 5-15RMini-TowerSimulated Sine Wave $154.95
 BRG1000AVRLCD 1000 VA600 W10 x NEMA 5-15RMini-TowerSimulated Sine Wave $169.95
 BRG1350AVRLCD 1350 VA810 W12 x NEMA 5-15RMini-TowerSimulated Sine Wave $209.95
 BRG1500AVRLCD 1500 VA900 W12 x NEMA 5-15RMini-TowerSimulated Sine Wave $239.95
